Specifications of AFX17251 AC Axial Fan
| Listed | Rated | Operating | Rated power | Rated Speed | Air | Static | Noise | Available Features (Optional) | Weight | |||
| Model | Voltage | Voltage | Flow | pressure | Level | |||||||
| （VAC） | （VAC） | （W） | （RPM） | （CFM） | (mmH2O) | (dBA) | 转速侦测 | 锁机报警 | 温控 | 脉冲调速 | g | |
| Tachometer | Rotation | Thermal | Pulse Width | |||||||||
| Output | Detector | Control | Modulation | |||||||||
| AFX175122L | 110/220 | 85~240 | 15.00 | 2,500 | 197.80 | 11.10 | 56.10 | ◆ | ◆ | ◆ | ◆ | 664 |
| AFX175122M | 85~240 | 35.00 | 3,500 | 277.00 | 21.80 | 64.90 | ◆ | ◆ | ◆ | ◆ | ||
| AFX175122H | 85~240 | 50.00 | 4,500 | 356.10 | 36.10 | 71.45 | ◆ | ◆ | ◆ | ◆ | ||
| Specifications are subject to change without notice | ||||||||||||
Description of AFX17251 AC Axial Fan
Frame: Die-cast Aluminum Alloy
Impeller: PBT OF UL 94V-0
Bearing Type: Ball Bearing
Lead Wires: UL Type or Equivalent ( + ) : Red ( - ) : Black
Motor Protection: Reverse Polarity Protected; Automatic Restart
Operating Temperature and Humidity: -10℃～70℃,5%～90%RH
Storage Temperature and Humidity: -40℃～80℃,5%～95%RH
