Specifications of DFX11018 Centrifugal Fan
| Listed | Rated | Operating | Rated Current | Rated Speed | Air | Static | Noise | Available Features (Optional) | Weight | |||
| Model | Voltage | Voltage | Flow | pressure | Level | |||||||
| （VDC） | （VDC） | （A） | （RPM） | （CFM） | (mmH2O) | (dBA) | g | |||||
| Tachometer | Rotation | Thermal | Pulse Width | |||||||||
| Output | Detector | Control | Modulation | |||||||||
| DFX111812H | 12 | 6.0~13.8 | 0.70 | 3,500 | 41.40 | 18.00 | 54.00 | ◆ | ◆ | ◆ | ◆ | 61 |
| DFX111812M | 6.0~13.8 | 0.50 | 3,000 | 35.50 | 13.20 | 50.00 | ◆ | ◆ | ◆ | ◆ | ||
| DFX111812L | 6.0~13.8 | 0.30 | 2,500 | 29.60 | 9.20 | 45.20 | ◆ | ◆ | ◆ | ◆ | ||
| DFX111824H | 24 | 12.0~27.6 | 0.35 | 3,500 | 41.40 | 18.00 | 54.00 | ◆ | ◆ | ◆ | ◆ | |
| DFX111824M | 12.0~27.6 | 0.25 | 3,000 | 35.50 | 13.20 | 50.00 | ◆ | ◆ | ◆ | ◆ | ||
| DFX111824L | 12.0~27.6 | 0.15 | 2,500 | 29.60 | 9.20 | 45.20 | ◆ | ◆ | ◆ | ◆ | ||
| X=S: Sleeve Bearing or B: Ball Bearing or H: Hydro Bearing; Specifications are subject to change without notice | ||||||||||||
Description of DFX11018 Centrifugal Fan
Frame: PBT OF UL 94V-0
Impeller: PBT OF UL 94V-0
Bearing Type: Sleeve Bearing & Ball Bearing& Hydro Bearing
Lead Wires: UL Type or Equivalent ( + ) : Red ( - ) : Black
Motor Protection: Reverse Polarity Protected; Automatic Restart
Operating Temperature and Humidity: -10℃～70℃,5%～90%RH
Storage Temperature and Humidity: -40℃～80℃,5%～95%RH
